1. Select model and size

29" - Alpha Blue
29" - Red
29" - Black

2. Related Products

5.842 €

FACTORY AXS 01 2023

KEY FEATURES
· Construction FSC Technology carbon frame with internal wiring
· Fork Fox 32 Factory StepCast Kashima FIT4 100 mm
· Sram XX1 AXS 12s transmission
· Shimano XT 8100 breaks
· Maxxis Rekon Race 29 x2,35 tubeless wheels
Wheel29"SizeSMLXL
Price5.842 €
DON´T KNOW WHAT SIZE YOU NEED?
Add your body measurements in our size calculation system to guide you between the measurement ranges of your bicycle.
Calculate your size
CALCULATE YOUR SIZE
Tell us some basic information, we recommend the most appropriate size for your measurements.
I am a...
/
Fill the field
This result is indicative, if you want a more specific setting we recommend making a fitting with experts.
Previous Next Contact us
Contact your dealer if you need advice
Find your store Compare model
Comparator of models

Technical information

Frameset
Frame 29 Factory Carbon Construction FC Technology BB92, Boost 12x148mm
Fork Fox 32 Factory StepCast Kashima FIT4 100 mm Remote Lockout, 15x110 Boost
Headset Full Integrated Megamo
Drivetrain
Rear Derailleur Sram XX1 AXS 12s
Shifters Sram AXS Controller
Crankset Sram XX1 AXS 12s 32t
Cassette Sram XX1 AXS 12s 10-52t
Brakes
Brakes Shimano XT 8100
Wheels
Tires Maxxis Rekon Race 29x2,35 - Tubeless Ready, EXO, Foldable, 120 TPI
Hubs
Wheels
Components
Handlebar Full Integrated Carbon handlebar Megamo -17º/60mm/780mm or -17º/80mm/780mm
Seatpost Megamo Elite Light SP 30,9
Seat Selle Italia SLR Boost X-Cross Superflow

*Due to ongoing problems and delays in the supply chain, Megamo reserves the right to change any component, if necessary by replacing it with an equivalent one, without prior notice.

Geometry FACTORY AXS 01 (23)

    S M L XL
A
T/T 575 600 625 650
B
C/S 425 425 425 425
C
S/T 390 440 480 530
D
H/T 95 100 115 125
E
REACH 404 429 449 471
F
STACK 595 600 614 624
G
FRONT ANGLE 69.5º 69.5º 69.5º 69.5º
H
REAR ANGLE 74º 74º 74º 74º
I
WHEEL BASE 1085 1111 1137 1163
J
BB DROP 58 58 58 58
K
FRONT WHEEL BB 667 693 718 745
  FIT GUIDE SMALL
165 - 175
MEDIUM
170 - 185
LARGE
180 - 190
X-LARGE
190 - 210
