Cuadro | Full Integratted Battery, Alloy Triple Butted, 12x148 Boost, Horst Link 4, Wheel travel: 150 mm, Tire clearance 29 x 2.6 |
 |
Horquilla | FOX 34 Rhythm e-Bike, Float 29, 150mm, grip, sweep-adj, 15QRx110 Boost, 44mm rake |
 |
Amortiguador | FOX Float DPS, Performance Series, 3pos, Trunnion, Evol LV, 205x65 |
 |
Juego de dirección | FSA Orbit 1,5 E ZS 1-1/8” 1,5” |
 |
Motor | Shimano EP8 250W |
 |
Batería | Integrated LI-ION Battery, 630 Wh |
 |
Display | Shimano EP8 |
 |
Cambio Trasero | Shimano Deore 12s |
 |
Manetas cambio | Shimano Deore 12s |
 |
Plato | Shimano 36t |
 |
Cassette | Shimano Deore 12s 10-51t |
 |
Conjunto de frenos | Shimano MT520 hydraulic disc 4-Piston, 203mm |
 |
Cubiertas | Front: 29x2,6 Maxxis Minion DHF, Rear: 29x2,6 Maxxis Minion DHR II, Tubeless Ready, EXO Protection / Pirelli Scorpion Eduro S HardWALL |
 |
Ruedas | 29 Asymmetric 15x110 12x148 Boost Wide:30mm Tubeless Ready |
 |
Manillar | Alloy Butted 31,8x780 mm, Rise: 12 mm, Back Sweep: 6º |
 |
Potencia | 3D Forged Alloy, Ext.: 60-70-90 mm, Rise: ±7º |
 |
Tija sillín | Megamo Ø30,9mm Dropper post, remote adjustment |
 |
Sillín | Selle Italia Model X |
*Debido a los persistentes problemas y retrasos en la cadena de suministro, Megamo se reserva el derecho a modificar cualquier componente, por uno de igual valor en caso de ser necesario, sin previo aviso. |
| S | M | L | |
|---|---|---|---|
| SIZE | 16 | 18 | 20 |
| T/T | 600 | 620 | 644 |
| C/S | 465 | 465 | 465 |
| S/T | 406 | 457 | 508 |
| H/T | 135 | 140 | 145 |
| REACH | 431 | 450 | 474 |
| STACK | 630 | 634 | 639 |
| BB HEIGHT | 370 | 370 | 370 |
| FRONT ANGLE | 65,3º | 65,3º | 65,3º |
| REAR ANGLE | 75º | 75º | 75º |
| L/T | 205x65 TR | 205x65 TR | 205x65 TR |
| REAR TRAVEL | 150 | 150 | 150 |
| WB | 1232 | 1253 | 1279 |
