Cuadro | Full Integratted Battery, Alloy Triple Butted, 12x148 Boost, Horst Link 4, Wheel travel: 150 mm, Tire clearance 29 x 2.6 |
 |
Horquilla | Fox 38 Factory e-bike+, Kashima 29, 160mm, grip 2, 15QRx110, 44mm rake |
 |
Amortiguador | FOX Float DHX2, Factory Series, Kashima 3pos-Adj, Trunnion |
 |
Juego de dirección | FSA Orbit 1,5 E ZS 1-1/8” 1,5” |
 |
Motor | Shimano EP8 250W |
 |
Batería | Integrated LI-ION Battery, 630 Wh |
 |
Display | Shimano EP8 |
 |
Cambio Trasero | Shimano XT 12s |
 |
Manetas cambio | Shimano Deore 12s |
 |
Plato | Shimano 36t |
 |
Piñón | Shimano deore 12s 10-51t |
 |
Conjunto de frenos | Shimano MT520 hydraulic disc 4-Piston, 203mm |
 |
Cubiertas | Front: 29x2,6 Maxxis Minion DHF, Rear: 29x2,6 Maxxis Minion DHR II, Tubeless Ready, EXO Protection |
 |
Bujes | Boost System 15x110 12x148, E-Bike+ |
 |
Ruedas | DT Swiss 1501 HX 30 - MSPLINE |
 |
Manillar | Alloy Butted 31,8x780 mm, Rise: 12 mm, Back Sweep: 6º |
 |
Potencia | 3D Forged Alloy, Ext.: 60-70-90 mm, Rise: ±7º |
 |
Tija sillín | FOX Transfer, Factory series (Kashima), Ø 30.9mm, Internal Routing, Remote |
 |
Sillín | Megamo Specific E-Bike+ Saddle |
Nos reservamos el derecho a modificar la información de la web sin previo aviso, incluido las especificaciones, modelos, colores y materiales. |
| S | M | L | |
|---|---|---|---|
| SIZE | 16 | 18 | 20 |
| T/T | 600 | 620 | 644 |
| C/S | 465 | 465 | 465 |
| S/T | 406 | 457 | 508 |
| H/T | 135 | 140 | 145 |
| REACH | 431 | 450 | 474 |
| STACK | 630 | 634 | 639 |
| BB HEIGHT | 370 | 370 | 370 |
| FRONT ANGLE | 65,3º | 65,3º | 65,3º |
| REAR ANGLE | 75º | 75º | 75º |
| L/T | 205x65 TR | 205x65 TR | 205x65 TR |
| REAR TRAVEL | 150 | 150 | 150 |
| WB | 1232 | 1253 | 1279 |
