7.149 €

CRAVE AL GRAVITY 2024

KEY FEATURES
· Shimano EP801 engine / 85 Nm
· 762 Wh built-in LI-ION battery
· Frame with fully integrated battery and central motor
· FOX 38 Kashima fork with 160 mm travel
· FOX Float DHX2 rear shock
· Shimano XT 12-speed transmission
· Shimano XT 4 Piston hydraulic disc brakes
Wheel29"SizeSML
Price7.149 €
DON??´T KNOW WHAT SIZE YOU NEED?
Add your body measurements in our size calculation system to guide you between the measurement ranges of your bicycle.
Calculate your size
CALCULATE YOUR SIZE
Tell us some basic information, we recommend the most appropriate size for your measurements.
I am a...
/
Fill the field
This result is indicative, if you want a more specific setting we recommend making a fitting with experts.
Previous Next Contact us
Contact your dealer if you need advice
Find your store Compare model
Comparator of models

Technical information

Frameset
Frame Full Integratted Battery, Alloy Triple Butted, 12x148 Boost, Horst Link 4, Wheel travel: 160 mm, Tire clearance 29 x 2.6
Fork Fox 38 Factory e-bike+, Kashima 29, 160mm, grip 2, 15QRx110, 44mm rake
Shock FOX Float DHX2, Factory Series, Kashima 3pos-Adj, Trunnion
Headset FSA Orbit 1,5 E ZS 1-1/8” 1,5”
Electronic components
Motor Shimano EP801 / 85 Nm
Battery Integrated LI-ION Battery, 762 Wh
Display Shimano Steps SC-EN600
Drivetrain
Rear Derailleur Shimano XT 12s
Shifters Shimano Deore 12s
Crankset Shimano 36t
Cassette Shimano Deore 12s 10-51t
Brakes
Brakes Shimano XT M8020 Hydraulic disc 4-Piston, 203mm
Wheels
Tires Front: 29x2,6 Maxxis Minion DHF, Rear: 29x2,6 Maxxis Minion DHR II, Tubeless Ready, EXO Protection / Pirelli Scorpion Eduro S HardWALL
Hubs DT Swiss 1700 HX 30 - Mspline
Wheels DT Swiss 1700 HX 30 - Mspline
Components
Handlebar Race Face Turbine R
Stem Race Face Aeffect
Seatpost FOX Transfer, Factory series (Kashima), Ø 30.9mm, Internal Routing, Remote
Seat Selle San Marco GrouND Short Open-fit Titanium

*Due to ongoing problems and delays in the supply chain, Megamo reserves the right to change any component, if necessary by replacing it with an equivalent one, without prior notice.

Geometry CRAVE AL GRAVITY (24)

    S M L
A
T/T 611 628 649
B
C/S 451 451 451
C
S/T 410 460 510
D
H/T 135 140 145
E
REACH 455 470 490
F
STACK 627 632 636
G
BB HEIGHT 361 361 361
H
FRONT ANGLE 64,3º 64,3º 64,3º
I
REAR ANGLE 73º 73º 73º
J
REAR TRAVEL 150 150 150
K
WB 1246 1263 1285
FIT GUIDE
SMALL
160 - 175
MEDIUM
175 - 185
LARGE
185 - 200
