2. Related Products

4.274 €

RAISE AXS 07 2023

KEY FEATURES
· Ultra-light carbon frame with fully internal cabling
· Sram Force AXS 12s transmission
· Vision Team 30 Disc-brake wheels
SizeXSSMLXL
Price4.274 €
DON??´T KNOW WHAT SIZE YOU NEED?
Add your body measurements in our size calculation system to guide you between the measurement ranges of your bicycle.
Calculate your size
CALCULATE YOUR SIZE
Tell us some basic information, we recommend the most appropriate size for your measurements.
I am a...
/
Fill the field
This result is indicative, if you want a more specific setting we recommend making a fitting with experts.
Previous Next Contact us
Contact your dealer if you need advice
Find your store Compare model
Comparator of models

Technical information

Frameset
Frame Carbon Advanced Composite frame, Full Internal Cable Routing, Flat Mount Disc Brakes 12x142
Fork Carbon Advanced Composite fork, Full Internal Cable Routing, Flat Mount Disc Brakes 12x100
Headset Totally Internal Cable routing
Drivetrain
Rear Derailleur Sram Force AXS 12s
Derailleur Sram Force AXS 12s
Shifters Sram Force AXS 12s
Crankset Sram Force AXS 12s 48-35 Powermeter
Cassette Sram Force AXS 12s 10-33t
Brakes
Brakes Sram Force AXS 12s
Wheels
Tires Pirelli P Zero RC TLR Classic / Vittoria Rubino Pro IV 700x28 TLR G2.0
Hubs Vision Team 30 Disc
Wheels Vision Team 30 Disc
Components
Handlebar Carbon Full Integratted Internal Cable Routing: 90/400 (XS), 100/400 (S), 110/420 (M,L), 120/440 (XL)
Seatpost Megamo 27,2mm
Seat Selle Italia Novus Boost Evo Superflow

*Due to ongoing problems and delays in the supply chain, Megamo reserves the right to change any component, if necessary by replacing it with an equivalent one, without prior notice.

Geometry RAISE AXS 07 (23)

    XS S M L XL
A
T/T 507 523 541 559 576
B
C/S 405 405 405 405 405
C
S/T 422 453 473 499 525
D
H/T 103 116 135 156 176
E
REACH 357 369 381 393 405
F
STACK 505 522 541 560 580
G
BB HEIGHT 270 270 270 270 270
H
FRONT ANGLE 70,5º 72º 72º 72º 72º
I
REAR ANGLE 73,5º 73,5º 73,5º 73,5º 73,5º
HANDLEBAR AND STEM INTEGRATED:
    XS S M L XL
  90/400 - - - -
  100/400 - - - -
  110/420 - - -
  120/440 - - - -

FIT GUIDE
X-SMALL
158 - 168
SMALL
165 - 172
MEDIUM
170 - 182
LARGE
182 - 190
X-LARGE
188 - 210
